一.參數說明

* 品牌 TCM

* 型號 DN40-6

* 材質  鑄鋼

* 性能 高溫高壓無泄漏

* 揚程130米

用途 冷凝水回收泵 高溫鍋爐給水高樓自來水輸送

泵軸位置 臥式

葉輪結構 封閉式葉輪

葉輪吸入方式 單吸式

流量  8 m3/h

葉輪數目6個

汽蝕余量1.8 m

軸功率7.5 kW

吸入口徑40/50 mm

排出口徑40/50 mm

結構原理 噴射式

二.泵性能選擇表

三.泵浦特點

四.泵浦詳細說明

1.整機進口,泵浦結構堅固,泵殼皆經水壓試驗,採用機械軸封,止漏效果好

 The machine imports, pumps, pump shell structure strong are the hydrostatic test, the mechanical shaft seal, stop leakage effect is good.

2.動葉輪皆經平衡校正運轉時不會振動

Move the impeller is balance correction, running not vibration.

3.經過特殊設計使用溫度可達180℃壓力可達30Kg/cm2

 With special design, using temperature of 180 ℃, the highest pressure can be up to 30 Kg/cm2

4.產品發展歷史久遠,性能優異品質可靠

 Product development long history, the outstanding performance, reliable quality.

用途:

USES:

高溫冷凝水回收高溫鍋爐給水自來水高壓輸送用

High temperature condensed water recycling, high temperature, high pressure boiler water transport use.

（不含馬達與底座需另外自行購買）

excluding motor and base additional purchase

產地***

Origin: Ta
